Product Details:
Payment & Shipping Terms:
|
| HS-Code: | 8705909990 | Cell: | 8615271357675 |
|---|---|---|---|
| Refuse Container: | 2 M3 | Sweeping Width: | 3 M |
| Sweeping Capacity: | 40000-60000m2 / H | Sweeping Efficiency: | (%) ≥90% |
| Sweeping Mode: | Dry Washing And Sweeping | Working Speed:: | 3-20km/h |
| High Light: | truck mounted road sweeper,vacuum sweeper truck |
||
JMC Road washing Sweeping Truck With 4 Brushes 5.5 cbm Trash 1,5 cbm Water
Vaccum Trash Tank 2000L
1. Equipped with four sweep brush street sweeper truck
2. Equipped with stainless steel 1m3 rubbish tank ,0.2m3 clean water tank street sweeper truck
3. Foton Forland 4x2 mini road sweeper truck for sale
4. High quality and low price of street sweeper truck
5. Efficient,fast and easy operation street sweeper truck
| Main parameters | Product model | DRZ5040TSLB4 sweeper truck |
| Gross weight (Kg) | 3600 | |
| Rated load (Kg) | 1100 | |
| Curb weight (Kg) | 2370 | |
| Cab seats | 2 | |
| Approach/departure angle | 22/15 | |
| Number of axles | 2 | |
| Axle load (Kg) | 1365/2235 | |
| Overall dimension(mm) | 4760×1678×2100 | |
| Front/rear suspension (mm) | 1010/1450 | |
| Wheel base(mm) | 2300,2300,2600 | |
| Max speed (Km/h) | 80 | |
| Chassis parameters | Chassis model | BJ1042V8PAA-G1 |
| Brand | Foton | |
| Dimentions | 4400×1678×1900 | |
| Approach/departure angle | 22/20 | |
| Plate spring No. | 8/6+3 | |
| Fuel | diesel | |
| Number of wheels (mm) | 6 | |
| Tire specification | 6.00-13 8PR | |
| Front track base (mm) | 1300 | |
| Rear track base (mm) | 1240 | |
| Engine capacity (ml) | 1809 | |
| Emission standard | Euro IV | |
| Sweeper parameters | Sweeping brush | 4 pcs |
| Sweep width (mm) | 3000 | |
| Cleaning capacity | 40000-60000m2 / h | |
| Cleaning speed | 3-20km/h | |
| Cleaning Efficiency | 90% | |
| maximum inhalation size | 120mm | |
| nozzle minimum ground clearance | 200mm | |
| Equiped with four sweep plate combined with the sucking mouth . Equiped with stainless steel rubbish tank ,clean water tank and dirty water tank |
||
| Main specifications | |||
| Product model,name | DRZ5040TSLB4 Road Sweeper Truck | ||
| Gross weight(Kg) | 3600 | Drive type | 4 × 2 |
| Payload (Kg) | 1100 | Overall dimension (mm) | 4760×1678×2100 |
| Curb weight(Kg) | 2370 | cab seats (man) | 3 |
| Approach / departure angle(°) | 22/15 | Front/rear hang(mm) | 1010/1450 |
| Number of axles | 2 | Wheelbase(mm) | 2600 |
| Axle load | 1365/2235 | Max speed(Km/h) | 80 |
| Chassis specifications | |||
| Chassis model | BJ1032V3JB3-S | Manufacturer | Beiqi Futian Motor Company Limited |
| Brand name | Foton | Overall dimension(mm) | 4600×1678×2100 |
| Tire specification | 6.00-15 | Tires No. | 6 |
| Steel spring number | 8/6+3,8/9 | Front track(mm) | 1300,1365 |
| Fuel type | Diesel | Rear track(mm) | 1240 |
| Emission standard | Euro III | Transmission | 5 forward gear |
| Cabin | Flat single row, the cab can flip forward, optional air conditioning | ||
| Engine model | Engine manufacture | Displacement(ml) | Power(Kw) |
| 4D22E | Anhui quanchai power Limited by Share Ltd | 2156 | 65 |
| Road Sweeper Performance | |||
| Trash tank volume (m³) | 2 | Water tank volume (m³) | 0.5 |
| Material of trash tank | Stainless steel | Material of water tank | Stainless steel |
| Model of auxiliary engine | YCD4K12T-55 | Power of auxiliary engine(Kw) | 41KW |
| Manufacturers of auxiliary engine | Guangxi yuchai machinery co., LTD | Max sweeping width(mm) | 3200 |
| Sweeping speed (km / h) | 3-20 | Sweeping capacity(m2/h) | 9000- 60000 |
| Maximum Grain size and quality (mm) | 100mm±1.5kg | Cleaning Rate | 96% |
| Road Sweeper Features | |||
|
1.The control box is in the cab, all kinds of system electrical centralized to control, and easy to operate! 2, Four scan disk combinated with suction nozzle in working. according to a different cleaning conditions Scan disk speed can be controlled by choosing three gear-High, medium and low, which can make sure there be have a good cleaning results in a variety of pollution status. and when met the obstacle, the scan disk can be have a automatic avoidance protections and features automatic reset function, and retracted automaticly, then reseted automaticly after over some obstacles! 3.Both of side of the scan disk can be working altogether, or unilateral work independently. 4.The core components of hydraulic systems adopts the original import! |
|||
